Tare weight:1000kg
Payload:40000kg
Overall length:12000mm
Overall width:2500mm
Overall height:4000mm
BULK CEMENT SEMI TRAILER
Tare weight:1000kg
Payload:40000kg
Overall length:12000mm
Overall width:2500mm
Overall height:4000mm
Description
| SPECIFICATION | ||||||
| Tank body | Q235A/6mm steel sheet shape:V type | |||||
| End plate | Q235A/6mm .ball shape | |||||
| Axle | Number | 3 | Brand | Optional upon choice | Capacity | 13T |
| Suspension | Mechanical suspension or air suspension |  | ||||
| Leaf spring | Leaf spring or air bag | |||||
| Manhole cover | 500mm manhole cover.2 sets | |||||
| Tire | 11.00R20,12.00R20,11R22.5,12R22.5,315/80R22.5 Tire optional | |||||
| Wheel rim | 8.5-20,9.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice | |||||
| Discharge valve | 4"disc valve | |||||
| Discharge pipe | 4"seamless steel tube | |||||
| Kingpin | 2”/3.5”bolt-in king pin | |||||
| Landing gear | JOST brand two-speed,manual operating,heavy duty landing gear | |||||
| Engine | Diesel engine or electrical motor | |||||
| Air compressor | 37 KW,0.2Mpa.1000r/Min | |||||
| Compartment | Single | |||||
| Braking system | WABCO RE6 relay valve;T30/30 spring brake chamber;40Lair tanks | |||||
| Painting | Complete chassis sand blasting to clean rust,1coat of anticorrosive prime,2coats of final paint | |||||
| Accessories | One standard tool box | |||||
| Air-charging system | 2”main hole,2“check valve,1.5”safe valve,0.4Mpa gauge | |||||
| Quadratic blow | 1"diameter check valve | |||||
| Outlet discharge pipe | 4”rubber hose.6m | |||||
